Model NO.:DM018
Sterilization:Ethylene Oxide Sterilization
Guarantee Period:5 Years
Group:Adult
Logo Printing:With Logo Printing
Length:1.25m
Transport Package:Carton
Specification:Single Packed
Trademark:According to customer requirements
Origin:China
Capacity:50,000,000 pieces
Key Composition:
- Piercing device: Made of medical grade white ABS, with or without air inlet, 3 or 4 holes size according to ISO8536-4 standard.
- Protective cap: Made of PP or PE.
- Drip chamber: Made of soft PVC, length 4.5cm - 7cm (ISO8536-4 standards).
- Fluid filter: ABS/PE support with nylon net, 15-micron mesh size.
- Air inlet: Red, white, or blue PP cap.
- Water-repellent filter: PP support, hydrophobic filtering paper (acrylic resin and nylon).
- Flow regulator: Made of PP or ABS, available in various shapes and sizes.
- Injection site: Latex, rubber, or synthetic rubber cone; Y-site made of hard transparent PVC.
- Soft tubing: Medical grade PVC, diameter 3X4mm, 150cm or 180cm length (adjustable).
- Terminal connector: PE/PVC, luer lock or luer slip.
- Assembly: Precision glued with solvent cyclohexanone.
Technical Specifications & Packing
Application: These sets are suited for hard containers and soft bags (without air inlet type).
Safety: Sterile, non-toxic, pyrogen-free, and sterilized by EOG.
Packing Details:
- 1 PC per Individual package
- 25 PCS per Middle paper box
- 20 Bags per Carton (Carton size varies based on specific product volume)
Q1: What sterilization method is used for these infusion sets?
A: All sets are sterilized using Ethylene Oxide (EO) to ensure they are sterile and safe for medical use.
Q2: Can the tube length be customized?
A: Yes, while standard lengths are 150cm and 180cm, the tube length can be adjusted according to your specific requirements.
Q3: Are these infusion sets suitable for soft bags?
A: Yes, the types without air inlets are specifically suited for use with soft infusion bags.
Q4: What is the shelf life of the product?
A: The quality guarantee period for this product is 5 years from the date of manufacture.
Q5: Is the product pyrogen-free?
A: Yes, the infusion sets are certified to be non-toxic and pyrogen-free.
Q6: Do you support custom logo printing?
A: Yes, we provide logo printing services based on the customer's specific branding requirements.
